PE Spiral Tubing
PE Spiral Tubing

VSL-BH01

PE Spiral Tubing

APPLICATION

  • VSL-BH01 is made of PE or Flame Retardant PE. It is widely used to protect wire from abrasion and meantime to improve the beauty of wire bending.

  • Anti-abrasion

    Make the wire neat and beautiful

  • Material PE/ Flame retardant PE
    Working Temperature -40~80℃
    Certificate RoHS
    Color Black, White(flame retardant)
  • Size-I.D.(mm) O.D.(mm) pitch(mm) W.T.（mm） Binding range(mm) Packaging(m/bag)
    3.00 4.00 6±0.1 0.45±0.05 4-50 50
    4.00 5.00 7±0.1 0.50±0.05 4-50 50
    5.00 6.00 8±0.1 0.50±0.1 4-50 20
    7.00 8.00 10±0.1 0.60±0.05 6-60 12
    9.00 10.00 12±0.1 0.60±0.05 7.5-60 10
    10.40 12.00 14±0.1 0.75±0.05 9-65 8
    12.00 14.00 16±0.1 0.90±0.05 12-75 6
    13.00 16.00 18±0.1 1.00±0.05 12-80 4
    16.00 18.00 20±0.1 1.10±0.1 14-90 3.5
    17.00 20.00 22±0.1 1.10±0.1 15-100 3
    22.00 25.00 24±0.1 1.20±0.1 15-110 -
    27.00 30.00 26±0.1 1.30±0.1 15-120 -

    Notes: Special size or color is available if you request.
